LSW-30 30kw Portable Electric IGBT Induction Brazing Welding
Equipment
1. Feature of high frequency Induction Brazing Machine:
1) EASY TO MOVE: for complex and inaccessible workpieces or
workshop locations, hand-held type is small-sized, simple operation
and move easily, it can easily do induction brazing.
2) QUIET AND COMFORTABLE: Induction heating is quiet and
comfortable, it won't cause the temperature surrounding environment
to rise.
3) STRONG CONTROLLABILITY: The controllable induction heating and
accurate heat transfer reduce the risk of overheating, thus
avoiding the damage to the workpiece and reducing the loss to the
maximum extent.
4) ACCURATE OPERATION: High frequency, stable heating output, no
vibration during working heating, accurate welding position, the
minimum diameter 0.1mm of metal can be welded and the sensor can be
customized according to the different shape of the workpiece.
5) REDUCE COST: Efficient and accurate heating ensures the
qualification of primary welding, making the waste, rework and
energy consumption to the minimum extent.
6) EASY TO OPERATE: When brazing, it is not necessary to carry or
store bulk workpiece near brazing equipment, it is an ideal choice
for online brazing.
2. Application of induction brazing machine:
1. metal tube welding:
such as copper tube, steel tube, and aluminum tube’s butt welding,
plug welding and welding sets.
2. alloy cutter welding:
such as alloy turning, milling cutter, planer, saw blades, reamer,
boring knife.
3. carbide saw blade welding:
diamond saw blade welding, marble saw blade welding,woodworking saw
blade welding, cut grass piece of welding, cut aluminum welding,
4. metal welding:
such as: towel rack, soap nets, towel holder,
auto-accessories,motor accessories, metal terminals, hardware
pieces, electric heating tube parts and fasteners.
5. customized service:
make machine according to customers' actual working situation.
3. Induction Brazing Equipment Brief Introduction :
Our induction brazing machine model is suitable to used for the
brazing of circular saw and other tools, usually 4 to 9 seconds is
needed to braze one diamond blade.
high frequency induction heating equipment is particularly suitable
for heat treatment and quenching, melting, annealing, the metal
through the heat forging, extrusion, welding, brazing.
3. Technical Parameters of LSW-30 Induction Brazing Equipment:
| Model | LSW-30 |
| Working Voltage | 380V, 50/60HZ |
| Max input power | 30kw |
| Oscillation frequency | 25-40KHZ |
| Duty cycle | 100% |
| Cooling water flow | 25L/Min,0.15-0.2MPa |
| Weight | 48kg |
| Dimension (L*W*H ) | 690*290*600mm |
| Material | stainless steel |
| Color | support customized |
| Usage | metal heating, brazing,melting etc |
4. Packaging Of Induction Brazing Machine:
As for packaging of induction heating machine: The machine is always packed with wrapping film for waterproof,
and then put into a standard exporting plywood case with foam
around for shockproof.
As for shipping of induction heating machine:
1. If you have a shipper in China, we can send the machines to him
or her for free.
2. If you want us to send the machines to you directly, we can send
them to any main port of China promptly.
5. Company Brief Introduction:
Zhengzhou Lanshuo Electronics Co.,Ltd. is located in Zhengzhou
National High-tech Industrial Development Zone.We are specialized
in R&D,design,production,complete sets of high frequency medium
frequency induction heating machine,with importing & exporting
managerial authority and a import & export of industrial furnace
franchising enterprises.
Our leading products include series and parallel technology IGBT
medium frequency heating equipment,IGBT super audio heating
equipment,CNC quenching machine tool,closed cooling tower,complete
quenching one device,forge heating smelting equipment.
